Zyxel Nebula NAP303 / Radio access point / 802.11a/b/g/n/ac / Dual Band / in-ceiling | NAP303-ZZ0101F
Zyxel Nebula NAP303 / Radio access point / 802.11a/b/g/n/ac / Dual Band / in-ceiling | NAP303-ZZ0101F
Description The Zyxel Nebula NAP303 802.11ac Dual-Radio Smart Antenna 3x3 Nebula Cloud Managed Access Point is a high-performance 3x3 802.11ac Wi-Fi AP capable of delivering combined data rates of up to 1.75 Gbps. Featuring Smart Antenna technology, the NAP303 perfectly solves coverage problems by adjusting antenna patterns adaptively to fit different wireless environments. The NAP303's industry-leading RF output power and sensitivity jointly offer greater coverage and better performance to networks. The ultra-fast capabilities makes NAP303 perfect for interference-laden environments, such as conference rooms, airports, educational facilities and other high-density venues. Zyxel Nebula NAP303 / Radio access point | NAP303-ZZ0101FSpecial Features
Product features
|
Product Specification
Device Type | Radio access point |
Width | 23.6 cm |
Depth | 22.7 cm |
Height | 6.2 cm |
Weight | 982 g |
Form Factor | In-ceiling |
Connectivity Technology | Wireless |
Data Transfer Rate | 1.75 Gbps |
Line Coding Format | DBPSK, DQPSK, CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Remote Management Protocol | NETCONF |
Frequency Band | 2.4 GHz, 5 GHz |
Status Indicators | Power, WLAN |
Features | VLAN support, DiffServ support, MAC address filtering, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), 3T3R MIMO technology, DHCP client, cloud managed, packet aggregation A-MPDU, packet aggregation A-MSDU |
Encryption Algorithm | TLS, PEAP, TTLS, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WEP |
Authentication Method | RADIUS, Radio Service Set ID (SSID), Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM, EAP-AKA |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3au |
Antenna | Internal |
Antenna Qty | 6 |
Interfaces | 2 x 1000Base-T (PoE) - RJ-45 ¦ 1 x console - RJ-45 |
MTBF | 1,202,489 years |
Compliant Standards | EN55022, EN55024, FCC Part 15 C, IEC 60950-1, EN 60950-1, FCC Part 15 E, BSMI CNS 13438, EN 60601-1-2, BSMI CNS 14336-1, EN61000-3-2, EN61000-3-3, EN 301.489-17, EN 301 489-1, LP0002, ETSI EN 300 328, EN 301 893 |
Power Over Ethernet (PoE) Supported | PoE |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
