Zyxel NWA220AX-6E / Radio access point / Wi-Fi 6 / 2.4 GHz, 5 GHz, 6 GHz / cloud-managed | NWA220AX-6E-EU0101F
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Radio access point |
| Width | 18 cm |
| Depth | 18 cm |
| Height | 4.2 cm |
| Weight | 650 g |
| Localisation | Europe |
| Networking | Networking |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, 802.11ax |
| Network / Transport Protocol | IPv6 |
| Remote Management Protocol | SNMP |
| Cloud-Managed | Yes |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum data rate (2.4 GHz): 575 Mbps ¦ Maximum data rate (5 GHz): 4800 Mbps ¦ Maximum data rate (6 GHz): 4800 Mbps |
| Features | Load balancing, VLAN support, MAC address filtering, Wireless Distribution System (WDS) support, firmware upgradable, Wi-Fi Multimedia (WMM) support, Advanced Cellular Coexistence (ACC), cloud managed, ZyXEL Wireless Optimizer (ZWO), MU-MIMO technology, Unscheduled Automatic Power Save Delivery (U-APSD), band steering, Fast Roaming, Dynamic Channel Selection (DCS), ZON Utility, L2-isolation, rogue AP detection |
| Encryption Algorithm | WPA, WPA2, WPA2-PSK, WEP, WPA3, WPA3-Enterprise |
| Authentication Method | RADIUS, Extensible Authentication Protocol (EAP) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.11k, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ac Wave 2, IEEE 802.11ax |
| Aerial | Aerial |
| Antenna | Internal |
| Gain Level | 6 dBi |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 1/2.5GBase-T (uplink, PoE+) - RJ-45 ¦ 1 x 1000Base-T - RJ-45 |
| Miscellaneous | Miscellaneous |
| Included Accessories | Mounting screws, mounting plate |
| MTBF | 711,333 hour(s) |
| Compliant Standards | EN55022, EN55024, FCC Part 15 B, FCC Part 15 C, FCC Part 15 E, BSMI CNS 13438, EN 60601-1-2, BSMI CNS 14336-1, EN 301 489-1, LP0002, ETSI EN 300 328, EN 301 893, IEEE 802.3af, IEEE 802.3at, EN 301 489-17, IEEE 802.3bt, EN 62368, EN 303 687 |
| Power | Power |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Power Device | External power adapter |
| Voltage Required | DC 12 V |
| Power Consumption Operational | 21 Watt |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 19.7 cm |
| Shipping Depth | 19 cm |
| Shipping Height | 6 cm |
| Shipping Weight | 780 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 95% (non-condensing) |
Features - Zyxel - NWA220AX-6E-EU0101F
More Details
Product Code
CF15992
EAN Code
4718937628643
Manufacturer
Zyxel
